可分离电缆终端系列
可分离连接终端
产品概述 Products overview 可分离式电缆终端广泛应用于箱式变压器、箱式环网柜、充电柜及电缆分支箱等带欧式 标准套管的设备柜体。具有体积小、重量轻、安全可靠、组合方便等特点
发布日期:2017-11-06 点击:711次
  • 产品图片
  • 性能指标
  • 产品视频



产品概述 Products overview

  可分离式电缆终端广泛应用于箱式变压器、箱式环网柜、充电柜及电缆分支箱等带欧式标准套管的设备柜体。具有体积小、重量轻、安全可靠、组合方便等特点。适用于配电网络的应用,切拆装灵活、全密封、全绝缘、全防护、免维护、抗淹没、抗污秽。同时表面包覆有一层半导体电屏蔽层,在正常工作或接地良好的情况下,即使操作人员接触了产品表面,也不会造成对人员伤害和设备损坏,大大提高了设备使用时的安全性和供电可

靠性。

  可分离式电缆终端均采用进口硅橡胶制作而成。该材料具有良好的绝缘性能,而电晕性及抗电痕性。能够加强电缆附件对电器系统波动的使用能力,使其在电气性能上与电缆的要求匹配,且具有阻燃性、自熄性能和优良的耐热性能,在电缆附件发生极端事故时,能够最大限度的降低事故后果并在一定程度上阻止事故的蔓延,提高系统运行的可靠程度,同时具

有抗紫外线。抗氧化、憎水迁移性强、对人体无毒无害等特点,适用于特殊场合及污秽严重环境。

  可分离式电缆终端均符合DIN47636标准,设计规范符合IEC 605022标准,实验要求符合IEC 60502:4标准实验方法符合GB/T12706.4-2002完善的规章管理制度及严格的

质量控制体系。确保了产品出厂品质。



    Can separate cable terminal are widely used in box transformer, box type ring netwlrk cabinet,chargers and cable branch box, etc with European standard cacsing equipment abinet put oneself in another's position.it is characterized by small volume,light weight,safe and reliale,combination is convenient wait for a characteristic. Suitable for distribution network applications.cut dismantling agile, whole sealing, full insulaton, full protection, free maintenance, resisting flood, resist filth, At the same time, surface coated with a layer of semiconductor electric shielding layer, in normal work or ground good circumstances,  even if the operating personnel contact the product surface, also won't be caused the personnel injury and equipment damage, greatly improving the equipment use safety and power supply reliability

  Can separate cable terminal are imported silicaone rubber is made and be become. The material has good insulating property, resistance to corona resistance and resistance to electric mark sex.To strengthen the cable accessories of electrical system fluctuation use ability, in the electrical properties and cable requirements matching, and has the flame retardancy, automatic quench can and good heat resistance, in cable accessories happen extreme accident, can maximum limit reducing accident consequences and to a certain extent, prevent the spread of the accident and improve the reliability of the system operation and at the same time with ultraviolet light resistance, resistance to oxidation and hydrophobic mobility strong, being harmless for healthetc., suitable for special occasions and polluted environment seriously

  Can separate cable terminal which conform IO the DIK147636 standards, design specifications conform to the IEC 60502-2 standars, the requirement of experiment operator joint IEC 60502-4 standard experimental methods accord with GB/T12706.4-2002. The perfect rules and management system and strict quality control system. Ensure that the manufactured products quality.
